Dimension: 70 x 20 x 6.5mm
Capacity: 128MB, 256MB, 512MB, 1GB, 2GB, 4GB, 8GB, 16GB, 32GB, 64GB, 128GB, 256GB.
USB Version: USB 2.0 and USB 3.0.
Available Colors: Black, White, Silver, Red, Blue.
Minimum Order Quantity: 25 pieces and Flexible.
Lead Time: 4~8 working days after proof approval.
| Mechanical characters | ||
|---|---|---|
| Item | Test condition | Allow condition |
| Ball Drop Test | 0.5J |
Steel ball drop down to AGcenter ,after 3 times, the ag still safety |
| Hardness |
Pencil:6H Pressure:500g/45° |
Hardness≧6H |
| life | Touch times | ≧1000000 times |
| FPCPulling test |
Pull angle：90° Pull speed :50mm/min |
Strength ≧ 500gf/cm |
| Optical characters | ||
|---|---|---|
| Item | Test condition | Allow condition |
| V/A transmission | 550nmnm | ≧83% |
| Camera hole through rate | 550nmnm | ≧90% |
| IR hole through rate | 840nmnm | 5%≦T≦25% |
|
Electricity characters Power need connect with GND, controller board 、 Metal cover and power board connected GND together |
|
|---|---|
| Item | Spec. |
| Interface | USB2.0 full speed |
| Power Supply | USB |
| working voltage | DC 5V±5% |
| <100mA | |
